HV-SDL-CL-05 Smart Cabinet Lock with Fingerprint, Password & HawkSmart App Access
The Hawk Vision HV-SDL-CL-05 Smart Cabinet Lockis a compact and modern smart locking solution designed for drawers, cabinets, lockers, cupboards, storage units, and similar furniture applications. Built withABS materialand a sleekblack finish, this smart cabinet lock offers convenient and secure access throughfingerprint, password, and HawkSmart mobile appverification.
With support for up to 50 fingerprints,50 passwords, and50 cards, the HV-SDL-CL-05 is suitable for personal, office, commercial, and storage security use. The lock features fast fingerprint identification inless than 1 second, optional500DPI fingerprint sensor, low power consumption, and long battery life of approximately5000 times / 6 months.
The smart cabinet lock is powered by alkaline batteries and includes Type C backup power support, making it practical for daily use. It is applicable fordrawer, cabinet etc., and is designed to work in a wide operating temperature range from-25°C to 55°C.
Website: www.hawkvisionindia.com
Key Features
-
Smart cabinet lock for drawer, cabinet etc.
-
3-way access: Fingerprint, App, and Password
-
HawkSmart mobile app support
-
Fingerprint capacity: 50
-
Password capacity: 50
-
Card capacity: 50
-
Fast fingerprint identify time: <1s
-
Optional 500DPI fingerprint sensor
-
ABS material body
-
Black color finish
-
Type C backup power: Yes
-
Battery life: 5000 times, approx 6 months
-
Suitable for cabinets, drawers, lockers, and storage units
Product Specifications
|
Specification |
Details |
|
Model No. |
HV-SDL-CL-05 |
|
Product Type |
Smart Cabinet lock |
|
Materials |
ABS |
|
Color |
Black |
|
Plate Size |
88L × 50W mm |
|
3-Way Access |
Fingerprint, App (HawkSmart) and Password |
|
App Name |
HawkSmart |
|
Verification Type |
Fingerprint, Password and mobile app |
|
Fingerprint Capacity |
50 |
|
Password Capacity |
50 |
|
Card Capacity |
50 |
|
Fingerprint Sensor |
Optional (500DPI) |
|
Fingerprint Identify Time |
<1s |
|
Fingerprint Verify Mode |
01:N |
|
Fingerprint False Rejection Rate |
<0.15% |
|
Power Supply |
3pcs AAA alkaline batteries |
|
Power Supply |
4.5–6.5V (4PCS AA Alkaline battery) |
|
Working Current |
<250 mA (Strong drive capability) |
|
Current Consumption |
<200mA |
|
Battery Life |
5000 times (approx 6 months) |
|
Type C Backup Power |
Yes |
|
Relative Humidity |
20% to 93% |
|
Working Temperature |
-25~55 Degree |
|
Operating Temperature |
-25°C ~55°C |
|
Applicable For |
Drawer, cabinet etc. |
|
Website |
